Black Painting OCTG Tubing 50mm Transportation Oil For Mechanical Structure

Name: Black Painting OCTG Tubing 50mm Transportation Oil For Mechanical Structure
Brand: L80-13%Cr
Price: 1 USD

Brand Name : L80-13%Cr

Model Number : 2-3/8"--4-1/2"

Certification : ISO API CE

Place of Origin : China

MOQ : 20ton

Price : USD

Payment Terms : T/T, L/C

Name : OCTG Tubing

Material Grade : L80-13%Cr

Standard : API 5CT

Size : 2-3/8"--4-1/2"

Grade : API K55

Length : 1-12m

Usage : Oil recovery

Contact Now

API 5CT , L80-13%Cr Transportation Of Crude Oil Tubing

used for the transportation of crude oil

and natural gas from an oil or gas layer to the surface

after drilling is complete. It is made to withstand the

pressure generated from the extraction process.

O.D.	Nominal mass		O.D.		w.t.		Nominal weight		Type of pipe end
	(lb/ft)						(kg/m)		Type of pipe end
	Threaded and coupled						Threaded and coupled		Grade
In.	NUE	EUE	In.	mm	In.	mm	NUE	EUE	J-55	L-80	N-80	C-90	T-95	P-110
2 3/8"	4.00	--	2.375	60.32	0.169	4.24	5.95	--	PN	PN	PN	PN	PN	PNU
	4.60	4.70	2.375	60.32	0.190	4.83	6.85	6.99	PNU	PNU	PNU	PNU	PNU	PNU
	5.80	5.95	2.375	60.32	0.254	6.45	8.63	8.85	--	PNU	PNU	PNU	PNU	--
	6.60	--	2.375	60.32	0.295	7.49	9.82	--	--	P	--	P	P	--
	7.35	7.45	2.375	60.32	0.336	8.53	10.94	11.09	--	PU	--	PU	PU	PNU
2 7/8"	6.40	6.50	2.375	73.02	0.217	5.51	9.52	9.67	PUN	PNU	PNU	PNU	PNU	PNU
	7.80	7.90	2.375	73.02	0.276	7.01	11.61	11.76	--	PNU	PNU	PNU	PNU	PNU
	8.60	8.70	2.375	73.02	0.308	7.82	12.80	12.95	--	PNU	PNU	PNU	PNU	--
	9.35	9.45	2.375	73.02	0.340	8.64	13.91	14.06	--	PU	--	PU	PU	--
	10.50	--	2.375	73.02	0.392	9.96	15.63	--	--	P	--	P	P	--
	11.50	--	2.375	73.02	0.440	11.18	17.11	--	--	P	--	P	P	--
3 1/2"	7.70	--	3.500	88.90	0.216	5.49	11.46	--	PN	PN	PN	PN	PN	PNU
	9.20	9.30	3.500	88.90	0.254	6.45	13.69	13.84	PNU	PNU	PNU	PNU	PNU	--
	10.20	--	3.500	88.90	0.289	7.34	15.18	--	PN	PN	PN	PN	PN	PNU
	12.70	12.95	3.500	88.90	0.375	9.52	18.90	19.27	--	PNU	PNU	PNU	PNU	--
	14.30	--	3.500	88.90	0.430	10.92	21.28	--	--	P	--	P	P	--
	15.50	--	3.500	88.90	0.476	12.09	23.07	--	--	P	--	P	P	--
	17.00	--	3.500	88.90	0.530	13.46	25.30	--	--	P	--	P	P	--
4"	9.50	--	4.000	101.60	0.226	5.74	14.14	--	PN	PN	PN	PN	PN	--
	10.70	11.00	4.000	101.60	0.262	6.65	--	16.37	PU	PU	PU	PU	PU	--
	13.20	--	4.000	101.60	0.330	8.38	19.64	--	--	P	--	P	P	--
	16.10	--	4.000	101.60	0.415	10.54	23.96	--	--	P	--	P	P	--
	18.90	--	4.000	101.60	0.500	12.70	28.13	--	--	P	--	P	P	--
	22.20	--	4.000	101.60	0.610	15.49	33.04	--	--	P	--	P	P	--
4 1/2"	12.60	12.75	4.500	114.30	0.271	6.88	18.75	18.97	PUN	PNU	PNU	PNU	PNU	--
	15.20	--	4.500	114.30	0.337	8.56	22.62	--	--	P	--	P	P	--
	17.00	--	4.500	114.30	0.380	9.65	25.30	--	--	P	--	P	P	--
	18.90	--	4.500	114.30	0.430	10.92	28.13	--	--	P	--	P	P	--
	21.50	--	4.500	114.30	0.500	12.70	32.00	--	--	P	--	P	P	--
	23.70	--	4.500	114.30	0.560	14.22	35.27	--	--	P	--	P	P	--
	26.10	--	4.500	114.30	0.630	16.00	38.84	--	--	P	--	P	P	--
P-Plain; N-No threading and no coupling; U-Upset with threading and coupling

Black Painting OCTG Tubing 50mm Transportation Oil For Mechanical Structure

Product Tags:

black painting OCTG Tubing

50mm OCTG Tubing

OCTG Tubing for mechanical structure

Wholesale Black Painting OCTG Tubing 50mm Transportation Oil For Mechanical Structure from china suppliers

Black Painting OCTG Tubing 50mm Transportation Oil For Mechanical Structure Images
